| Protection Radius of BAKIRAL Lightning Rods as per NFC 17-102 Standard | ||||
| H (m) | Level | |||
| I | II | III | IV | |
| 2 | 31 | 35 | 39 | 43 |
| 3 | 47 | 52 | 58 | 64 |
| 5 | 79 | 86 | 97 | 107 |
| 10 | 79 | 88 | 99 | 109 |
| 20 | 80 | 89 | 102 | 113 |
| Protection Radius of BAKIRAL Lightning Rods as per NFC 17-102 Standard | ||||
| H (m) | Level | |||
| I | II | III | IV | |
| 2 | 31 | 35 | 39 | 43 |
| 3 | 47 | 52 | 58 | 64 |
| 5 | 79 | 86 | 97 | 107 |
| 10 | 79 | 88 | 99 | 109 |
| 20 | 80 | 89 | 102 | 113 |
| MODEL | RADIUS (mtrs) |
| ALFA S/J Δt 60µS | 107 |
| ALFA S/M Δt 60µS | 107 |
| ZUES Δt 60µS | 107 |
| RAIDEN-40 Δt 40µS | 84 |
| RAIDEN-20 Δt 20µS | 58 |
